Abatement Technologies AG8000PAS Dust Containment Cart – 750 CFM, 10’2″ Height

ICRA-Compliant Ceiling Work Above Negative Pressure: AG8000PAS with Integrated PAS750 Air Scrubber

The Abatement Technologies AIRE GUARDIAN AG8000PAS pairs a mobile dust containment cart with the HEPA-AIRE PAS750 portable air scrubber — delivering a fully integrated, ICRA-compliant negative pressure system purpose-built for above-ceiling maintenance in hospitals and critical care environments. The PAS750 produces over 750 CFM of HEPA-filtered airflow, drawing contamination away from occupied zones while the cart’s sealed polyester sleeve (CPAI-84 flame-retardant) contains debris at the ceiling level.

AG8000PAS Containment Cart: Integrated Air Scrubber System for Ceiling Maintenance

• 750 CFM HEPA air scrubber (PAS750): 99.97% filtration at 0.3 microns; up to 5 units daisy-chainable on a single 15A circuit via built-in GFCI receptacles — 1.9A peak draw per unit
• Adjustable height to 10’2″ (124″): Single-operator height adjustment via hand-crank or power drill; minimum lowered height 77.5″
• 900 lb cart load rating, 300 lb ladder rating: Aircraft-grade anodized aluminum frame with clear polycarbonate panels for visibility
• 16 ft 3-section fiberglass extension ladder: Included; allows overhead access without additional equipment on site
• Footprint 62″ × 32″ (157 cm × 81 cm): 54.5″H × 22″W door opening; secure locking casters for stability during operation
• 325 lb net weight (including ladder): Flame-retardant polyester sleeve meets CPAI-84 standard; 120 VAC, 60 Hz power requirement

Above-Ceiling Maintenance in Healthcare, Cleanrooms, and Regulated Construction

The AG8000PAS is engineered for facilities where ceiling work cannot stop normal operations — replacing ceiling tiles, installing fire suppression lines, pulling data or electrical cables, servicing HVAC ductwork, and changing air filters above occupied patient areas. The PAS750’s exhaust collar vents contaminated air to the exterior while the cart’s enclosure prevents particulate from escaping laterally. This configuration satisfies Joint Commission-audited ICRA Construction Category requirements, making it the preferred solution for infection control risk assessment compliance on active hospital floors. The cart’s compact 62″ length allows positioning in standard patient-room corridors, and the OSHA-compliant upper header design permits technicians to work safely above the ceiling plane without breaching adjacent tile zones.

Negative Pressure Performance and ICRA Compliance Detail

Creating verifiable negative pressure is the core requirement of ICRA Category III and IV projects. The PAS750 integrated into the AG8000PAS generates airflow that exceeds hospital infection control standards established by NFPA life safety codes — drawing air inward through the cart’s sealed sleeve so that any airborne particulate released above the ceiling is captured before it can migrate into occupied spaces. The PAS750 carries NRTL certification and complies with applicable OSHA, UL, and CSA electrical safety standards. For facilities billing abatement work through Xactimate, the PAS750 is a recognized line-item unit (AQRS code), simplifying insurance documentation for restoration contractors working in healthcare or commercial construction. The variable-speed blower also allows airflow tuning to match room volume when precise air-changes-per-hour documentation is required by the infection control officer.

Video

Documents

AG8000PAS Mobile Dust Containment Cart — Product Data Sheet
HEPA-AIRE PAS750 Portable Air Scrubber — Product Data Sheet
