Autel CV ADAS LDW Calibration System – Lane Departure Warning Package
Original price was: £10,148.70.£5,581.79Current price is: £5,581.79.
[/description]
Features & Specs
Advanced Driver Assistance System (ADAS) is becoming standard equipment on today’s new vehicles. These systems are designed to assist drivers to prevent collisions by displaying alerts, providing camera images or by taking instantaneous control of the vehicle. The Autel MaxiSys CV ADAS provides the original complete diagnostic functionality, comprehensive and precise ADAS calibration for Light Duty 1-3 Class Vehicles. With MaxiSys calibration tools and accurate software, Autel MaxiSys ADAS is an ideal calibration tool for collision repair, glass replacement and repair shops.Â
Â
[/description]
What’s in the Box?
MaxiSys MS909CV Tablet Specifications
- Operating System: Android 7.0
- Processor: Samsung Exynos 8895V octa-core Processor (2.3GHz Quad-core Mongoose + 1.7GHz Quad-core A53)
- Memory: 4GB RAM & 128GB On-board Memory
- Display: 9.7-inch TFT-LCD with 1536 x 2048 resolution & capacitive touch screen
- Connectivity: WiFix2 (802.11 a/b/g/n/ac 2×2 MIMO)
- Connectivity: BT v.2.1 + EDR
- Connectivity: GPS
- Connectivity: USB 2.0 (TWO USB HOST Type A, ONE USB mini device)
- Connectivity: HDMI 2.0
- Connectivity: SD Card (Support up to 256GB)
- Camera (Rear): 16 Megapixel, Autofocus with Flashlight
- Camera (Front): 5.0 Megapixel
- Sensors: Gravity Accelerometer, Ambient Light Sensor (ALS)
- Audio Input/Output: Microphone
- Audio Input/Output: Dual Speakers
- Audio Input/Output: 3-Band 3.5 mm stereo/standard headset jack
- Power and Battery: 15000mAH 3.8V lithium-polymer battery
- Power and Battery: Charging via 12V AC/DC power supply with the temperature between 0°C and 45°C
- Input Voltage: 12V/3A Adapter
- Operating Temperature: 0 to 50°C (32 to 122°F)
- Storage Temperature: -20 to 60°C (-4 to 140°F)
- Dimensions (W x H x D): 304.4 mm (11.98″) x 227.8 mm (8.97″) x 42.5 mm (1.67″)
- Weight: 1.66kg (3.66 lb.)
- Protocols: DoIP, PLC J2497, ISO-15765, SAE-J1939, ISO-14229 UDS, SAE-J2411 Single Wire Can(GMLAN), ISO-11898-2, ISO-11898-3, SAE-J2819 (TP20), TP16, ISO-9141, ISO-14230, SAE-J2610 (Chrysler SCI), UART Echo Byte, SAE-J2809 (Honda Diag-H), SAE-J2740 (GM ALDL), SAE-J1567 (CCD BUS), Ford UBP, Nissan DDL UART with Clock, BMW DS2, BMW DS1, SAE J2819 (VAG KW81), KW82, SAE J1708, SAE-J1850 PWM (Ford SCP), SAE-J1850 VPW (GM Class2)
Videos
Docs
Assembly Instruction
Autel Calibration Frame Assembly Instructions (.pdf)
Autel Crossbar Assembly Instructions (.pdf)
Autel Target Holder Assembly Instructions (.pdf)
Brochure
Autel CV ADAS Packages Brochure (.pdf)
Autel ADAS Calibration Brochure (.pdf)
Calibration Toolset
Autel ADAS Tablet Frame Binding Instructions (.pdf)
Autel ADAS Compare Packages Brochure (.pdf)
Shipping & Details
1 Year Warranty
This tool is covered by our no-hassle Ironclad 1 Year Warranty
