Denray Model 4800 Tube Filtration Downdraft Table

This model is designed for larger jobs and can support two or three tasks operating simultaneously on the table. The 9600 is ideal for wood dust applications and features tube filtration with a 99% capture rate at 1 micron, providing a significantly superior filtration system compared to pleated filters. Standard features include a manual filter cleaning brush/handle, casters for mobility, and a rubber-coated top.

Product Information (Model 9600)

• 96″ x 48″
• 36″ height
• 930 lbs
• 3 HP motor
• 18″ fan
• 4300 CFM
• 81 decibels sound level
• 30 tube filters
• Casters
• 4 receptacles

Phase / Voltage Options (Model 9600)

SINGLE-PHASE
220 voltage (11.8 amps)

THREE-PHASE
230 voltage (8.2 amps)
460 voltage (4.1 amps)
575 voltage (3.4 amps)

Additional Options (Model 9600)

• Explosion-proof motor (3-phase only)
• Light bar
• Muffler (reduces sound level by 10–12 dBs)
• Three-sided hinged safety shield
• HDPE plastic tabletop
• Larger motor/fan upgrade

www.denray.com

Product Overview (Model 4800)

This model is well suited for medium-sized jobs and is ideal for wood dust applications. The 4800 model is equipped with tube filtration that provides a 99% capture rate at 1 micron, making it suitable for all wood dust environments. Standard features include a filter brush/handle for manual filter cleaning, casters for easy movement, and a rubber-coated top.

Product Information (Model 4800)

• 48″ x 48″
• 36″ height
• 580 lbs
• 2 HP motor
• 16.5″ fan
• 3400 CFM
• 77 decibels sound level
• 15 tube filters
• Casters
• 3 receptacles

Phase / Voltage Options (Model 4800)

SINGLE-PHASE
115 voltage (18.8 amps)
220 voltage (9.4 amps)

THREE-PHASE
230 voltage (5.8 amps)
460 voltage (2.9 amps)
575 voltage (2.4 amps)

Additional Options (Model 4800)

• Explosion-proof motor (3-phase only)
• Light bar
• Muffler (reduces sound level by 10–12 dBs)
• Three-sided hinged safety shield
• HDPE plastic tabletop
• Larger motor/fan upgrade
