iCarsoft CP V1.0 OBD2 Diagnostic Tool for Peugeot Citroen ABS SRS Oil Reset Battery

iCarsoft CP V1.0 OBD For Peugeot/Citroen Car Diagnostic Scan Tool Code Reader

For French Car Diagnostic Tools

iCarsoft CP V1.0 is a professional and powerful vehicle fault diagnosis tool for Peugeot/Citroen developed by iCarsoft Technology Inc. With a 2.8″ TFT LCD and unique diagnostic software, it features full Control Unit diagnosis of single vehicle brand and test modes mainly include: CANBUS, ISO9141, KWP2000, and J1850 etc. It enables technicians to accurately diagnose complex problems.

iCarsoft CP V1.0 OBD2 Diagnostic Code Scanner

FOR CITROEN PEUGEOT. F5

THIS PRODUCT IS 100% BRAND NEW & HIGH QUALITY

With Oil Service Reset, SAS Reset & Battery Test.

• 1. LCD DISPLAY — Indicates test results.

• 2. BACK BUTTON — Returns to previous menu.

• 3. UP BUTTON — Moves cursor up for selection.

• 4. DOWN BUTTON — Moves cursor down for selection.

• 5. LEFT BUTTON — Moves cursor up for selection.

• 6. RIGHT BUTTON — Moves cursor down for selection.

• 7. ENTER BUTTON — Confirms a selection (or action) from a menu list.

• 8. FUNCTION BUTTON — In case of special use.

• 9. FUNCTION BUTTON — In case of special use.

• 10. FUNCTION BUTTON — In case of special use.

• 11. HELP BUTTON — Shows help information for test results or user operation.

PRODUCT FEATURES

• iCarsoft CP V1.0 can do it all-reads and clears trouble codes on most of the Systems such as engine, transmission, ABS and airbag etc.

• Support OBDII/EOBD Ten Modes of Operation

• Read Live Data

• Full Control Unit Diagnosis

• Applies to the single Brand of all Models equipped with OBDII-16 DLC

• Easy To Use with Silicone Keys

• Oil Light/Service Reset: Support service lamp reset.

• The Print Data function allows you printing out diagnostic data recorded by The scan tool or customized test reports.

• Battery test allows you getting the voltage of battery with OBD port by the Scan tool when the engine starts.

• DTC Library to lookup when user is operating this tool.

• Upgrade via Computer

• Multi-language: English, German, Dutch, Spanish, French.

OBDII FUNCTION

• Read Codes

• Erase Codes

• I/M Readiness — I/M Readiness indicates whether or not the various emissions-related systems on the vehicle are operating properly and are ready for Inspection and Maintenance testing.

• Data Stream

• Freeze Frame — When an emission-related fault occurs, certain vehicle conditions are recorded by the on-board computer. This information is referred to as freeze frame data. Freeze Data is a snapshot of the operating conditions at the time of an emission related fault.

• O2 Sensor Test — This option allows retrieval and viewing of O2 sensor test results for most recently performed tests from the vehicle’s on-board computer.

• On-Board Monitoring — This function can be utilized to read the results of on-board diagnostic monitoring tests for specific components/systems.

• Evap System Test — The EVAP test function lets you initiate a leak test for the vehicle’s EVAP system. Before using the system test function, refer to the vehicle’s service repair manual to determine the procedures necessary to stop the test.

• Vehicle Information — The option displays the vehicle identification number (VIN), the calibration verification number (CVN), and other information of the test vehicle.

• Retrieve generic (P0, P2, P3, and U0), manufacturer specific (P1, P3, and U1) codes and pending codes

• Turn off Check Engine Light (MIL), clear codes and reset monitors

• Read live PCM datastream

• Support CAN (Controller Area Network) and all other

• Multilingual menu and DTC definitions- English, Spanish, and German, etc

CONTENTS

• CP V1.0 Main Unit

• User’s Manual

• TF Card (In the main unit)

• Main Cable

• PC Connecting Cable

• Nylon Carry Case

SPECIFICATIONS

• Display: 2.8″ TFT LCD, 320*240 Pixels

• Operation Temperature: 0°C ~ 50°C

• Storage Temperature: -20°C ~ 70°C

• Operating Voltage: 9 ~ 18V

• Operating Current: 150mA@12V (Typical)

• Power Consumption: 1.8W (Typical)

• Dimension: 187.510132 mm (L x W x H)
