Katool KT-TV910 Hydraulic Truck Tire Changer

TV910 Hydraulic Truck Tire Changer by Katool

Handling large truck tires does not have to involve excessive manual effort. The KT-TV910 Hydraulic Truck Tire Changer from Katool is engineered to manage demanding tire service tasks with power, efficiency, and control. Designed to accommodate outer rim sizes from 14 inches up to 42 inches and tires with diameters as large as 63 inches, it delivers exceptional versatility for heavy-duty applications. A 3.0 kW hydraulic motor provides smooth, reliable performance, while high working pressure and optimized oil flow support fast, consistent tire changes.

Despite its heavy-duty capability, the KT-TV910 maintains a practical overall weight for easier positioning within the workshop. Its low-noise operation helps maintain a more comfortable working environment. Built for professional workshops and industrial settings, this machine is a dependable solution for servicing truck, bus, tractor, and earth-moving vehicle tires.

Tire Changer TV910 Specifications

• Outer Rim Range: 14″–42″
• Max Wheel Diameter: 63″ / 1600 mm
• Max Wheel Width: 31″ / 780 mm
• Working Pressure: ≤130 bar
• Power Supply: 220V 1PH / 60Hz
• Hydraulic Motor: 3.0 kW (4.0 HP motor)
• Max Oil Flow for Hydraulic Motor: 315
• Max Tire Weight: 3,306 lbs / 1,500 kg
• Net Weight: 1,256 lbs / 570 kg
• Oil: AW-46 or AW-32 (for colder climates)

KT-TV910 Special Features

• Heavy-duty electro-hydraulic tire changer designed for trucks, buses, tractors, and earth-moving equipment
• Large external clamping capacity supports wheels from 14″ up to 42″ for maximum service flexibility
• Multifunctional control system allows safe operation from multiple positions
• Powerful bead and disk system delivers precise and efficient bead breaking, even on delicate rims
• Ergonomically positioned foot pedals and helper controls reduce training time and operator error
• Low-voltage electrical components enhance overall operator safety

Katool Warranty

• One-year (12-month) warranty covering all parts and manufacturing defects, free of charge

Available Combo Option

• KT-TV910 Tire Changer + KT-B795 Heavy-Duty Truck Wheel Balancer

Optional Items (Sold Separately)

• KT-B795 Heavy-Duty Truck Wheel Balancer
